Chapter 7 DIP
Switch Setting
<Note>
Please turn off the machin
e before changing DIP switch
setting.
7.1 DIP
SWITCH
7.1.1 OUTPUT
Swtich
Output Mo
de
Setting
Output Mo
de
Setting
1920x10
80/60
p
1920x10
80/50
p
1920x10
80/30
p
1920x10
80/25
p
1920x1080/60i
1920x1080/50i
1280x720/60p
1280x720/50p
1280x720/30p
1280x720/25p
1920x1080/59.94p
1920x1080/59.94i
1920x1080
/
29.97p 1280x7
20/59.94p
1280x720/29
.97p
