Lumex LF1050 User Manual

LF1050-INS-LAB-RevH18 11
CHARGING THE BATTERIES
Charge the batteries after assembly.
1. Ensure the battery box power switch is ON (i.e., the red button is up).
2. Insert the charger plug into the battery box charging socket (the top slot).
3. Insert the other charger plug into the power supply.
4. All LED indicator lights should illuminate during charging (see table below).
5. When one green LED indicator light illuminates, the batteries require approximately two to
three hours to be fully charged.
6. When only the red LED indicator light illuminates, the batteries require approximately seven to
nine hours to be fully charged.
s NOTICE: Do not charge the batteries for more than twelve hours.
7. Unplug the charger FIRST before using the lift.
Info: The lift will not operate while the batteries are charging.
The lift will not operate while the red reset button is down.
8. Replace the batteries when frequent charging is required.
Important Charging Information
Push lift to an appropriate location and charge the batteries with the charger provided.
s NOTICE: Avoid unplugging the hand control and motor from the control box. Frequent
plugging and unplugging of the hand control and motor to and from the control box may
damage the control box.
CHECKING BATTERY CAPACITY
Info: To check remaining battery capacity, press the battery indicator (blue circle with battery
symbol) while the lift is not in motion. Remaining battery capacity is indicated by LED
indicator lights and explained in the following table.
Red Amber Green Green Green Status
ON ON ON ON ON Fully charged
ON ON ON OFF OFF Needs charge
ON ON/OFF OFF OFF OFF Charge immediately—DO NOT use lift
ON OFF OFF OFF OFF Bad batteries or bad connection
ALARM BUZZERS
The control box has an alarm buzzer that provides information on the status of the batteries and
the lift. To stop the buzzer, push down the RED RESET button or press the battery indicator.
Buzzer type Status Note
2 beeps per second Low battery (red/amber lights illuminate) Charge batteries immediately
3 beeps per second Low battery (red light illuminates) Charge batteries immediately
6 beeps per second Very low battery (no lights illuminate) Charge batteries immediately
3 beeps every other second Bad battery (no lights illuminate) Replace batteries immediately
3 long beeps Overloaded. Batteries are charged but
lift does not lift
Maximum load capacity exceeded
