4. MEASURING PROCEDURE
If the test pins ( 3-7, Fig. 1 ) are not installed to the
probe head & packed separately, please refer the
following diagram to fix the test pins into the probe.
4-1 Measurement by selecting the different
material
1)Power on the meter by pushing the " Power button "
( 3-3, Fig. 1 ).
Remove the " Protection cover " ( 3-8, Fig. 1 ) away
from the " Test Pins " ( 3-7, Fig. 1 )
2)Press the" Material button " ( 3-6, Fig. 1 ) to select the
desired testing material.
Material 1 :
* 0 to 100% relative moisture value for
Concrete. and other non-wood material.
*
The right bottom display show " 1 "
Material 2 :
* 6 % to 40 % moisture range on wood.
*
The right bottom display show " 2 "
4
