LUX
MENU
F
˚
F
˚
SET
P
M
HEAT
OFF
COOL
AU TO
ON
FA N
TX9600TS
Set TemperatureRoom Temperature
Fan
Mode
Switch
System
Mode
Switch
Menu
Button
Clock
The electrical rating for this thermostat is 1.5 Amps per terminal, with a
maximum total combined load of 3.0A for all terminals combined.
COMPATIBLE WITH:
• Most 24-volt heating and cooling systems
• 1 or 2 stage Heat / 1 stage Cool: Gas, Oil or Electric systems
• 1 or 2 stage Heat / 1 stage Cool: Heat Pump systems
• 3-wire hydronic (hot water) zone valves
• Gas Millivolt heaters
NOT COMPATIBLE WITH:
• 120/240 VAC line-voltage systems (without a transformer), ask your LUX
dealer for thermostats to control these systems.
SYSTEM COMPATIBILITY:
2
