Makita 9404 User Manual

8
ASSEMBLY
CAUTION:
• Always be sure that the tool is switched off and
unplugged before carrying out any work on the tool.
Installing or removing abrasive belt
Pull the lever all the way out and install the belt over the roll-
ers, then return the lever to the original position.
CAUTION:
• When installing the belt, make sure that the direction of
the arrow on the back of the belt corresponds to the one
on the tool itself.
Adjusting belt tracking
Switch on the tool and make sure that the belt is aligned
properly. If the edge of the belt extends beyond the edge of
the base or the edge of the belt retracts more than 6 mm
(1/4”) away from the edge of the base, use the adjusting
knob to adjust the belt tracking.
Dust bag
Attach the dust bag onto the dust spout. The dust spout is
tapered. When attaching the dust bag, push it onto the dust
spout firmly as far as it will go to prevent it from coming off
during operation.
1. Lever
1
003501
003376
1. Steel plate
2. Adjusting knob
more than 6mm (1/4”)
1
2
003380
1. Dust bag
2. Dust spout
1
2
003385

Makita 9404 Specifications

General

Power	1010 W
Uncertainty K	1.5 m/s²
Dust container type	Dust bag
Type of sander	Belt sander
Dust extraction port	Yes
Power source	AC
AC input voltage	230 V

Weight and Dimensions

Depth	143 mm
Width	334 mm
Height	157 mm
Weight	4800 g
