Makita BTW104 User Manual

2
ENGLISH (Original instructions)
SPECIFICATIONS
Model BTW074 BTW104
Standard bolt M5 - M12 M5 - M12
Capacities
High tensile bolt M5 - M10 M5 - M10
Square drive 9.5 mm 9.5 mm
No load speed (min
-1
) 0 - 2,500 0 - 2,700
Impacts per minute 0 - 3,500 0 - 3,500
Max. fastening torque 65 N.m 95 N.m
Overall length 144 mm 144 mm
Standard battery cartridge(s)
Warning: Use only the battery cartridge(s) described.
BL1430A /
BL1415NA
BL1430A /
BL1415NA
Net weight 1.3 kg / 1.1 kg 1.3 kg / 1.1 kg
Rated voltage D.C. 14.4 V D.C. 14.4 V
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
END004-5
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･ Read instruction manual.
･ Only for EU countries
Do not dispose of electric equipment or
battery pack together with household
waste material!
In observance of European Directive
2012/19/EU on waste electric and
electronic equipment, 2006/66/EC on
batteries and accumulators and waste
batteries and accumulators and their
implementation in accordance with
national laws, electric equipment and
battery pack that have reached the end
of their life must be collected separately
and returned to an environmentally
compatible recycling facility.
ENE036-1
Intended use
The tool is intended for fastening bolts and nuts.
ENG905-1
Noise
The typical A-weighted noise level determined
according to EN60745:
Model BTW074
Sound pressure level (L
pA
) : 91 dB(A)
Sound power level (L
WA
) : 102 dB(A)
Uncertainty (K) : 3 dB(A)
Model BTW104
Sound pressure level (L
pA
) : 92 dB(A)
Sound power level (L
WA
) : 103 dB(A)
Uncertainty (K) : 3 dB(A)
Wear ear protection
ENG900-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745:
Model BTW074
Work mode : impact tightening of fasteners of the
maximum capacity of the tool
Vibration emission (a
h
) : 8.0 m/s
2
Uncertainty (K) : 1.5 m/s
2
Model BTW104
Work mode : impact tightening of fasteners of the
maximum capacity of the tool
Vibration emission (a
h
) : 8.5 m/s
2
Uncertainty (K) : 1.5 m/s
2
Cd
Ni-MH
Li-ion

Makita BTW104 Specifications

General

Brand	Makita
Model	BTW104
Category	Impact Driver
Language	English
