11ENGLISH
1
1. Carbon brush cap
4. Make sure to place the lead wire in opposite side
of the arm.
2
1
1. Lead wire 2. Carbon brush cap
5. Makesurethatthecarbonbrushcapshavetinto
the holes in brush holders securely.
1
2
1. Hole 2. Carbon brush cap
6. Reinstall the rear cover and tighten two screws
securely.
7.
Insert the battery cartridge into the tool and break in
brushes by running tool with no load for about 1 minute.
8. Check the tool while running and electric brake
operation when releasing the switch trigger. If electric
brake is not working well, ask Makita Authorized or
Factory Service Centers for repair.
To maintain product SAFETY and RELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual. The use of any other
accessories or attachments might present a risk of
injurytopersons.Onlyuseaccessoryorattachment
for its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• Drill bits
• Driver bits
• Tungsten-carbide tipped drill bit
• Blow-out bulb
• Driver bit holder
• Hook
• Makita genuine battery and charger
NOTE: Some items in the list may be included in the
tool package as standard accessories. They may
differ from country to country.

Makita DHP482 Specifications

General

Voltage	18V
No Load Speed (High)	0-1, 900 RPM
No Load Speed (Low)	0-600 RPM
Chuck Capacity	13mm
Max. Drilling Capacity in Steel	13mm
Max. Drilling Capacity in Wood	38mm
Max. Drilling Capacity in Masonry	13mm
Max Torque (Soft)	36Nm
Battery Type	Li-ion
Length	198mm
Blows per Minute (High)	0-28, 500 BPM
Blows per Minute (Low)	0 - 9, 000 IPM
Weight	1.5 - 1.8 kg
