Makita DHP482 User Manual

6 ENGLISH
Indicating the remaining battery
capacity
Only for battery cartridges with "B" at the end of the
model number
1
2
1. Indicator lamps 2. Check button
Press the check button on the battery cartridge to indi-
cate the remaining battery capacity. The indicator lamps
light up for few seconds.
Indicator lamps Remaining
capacity
Lighted Off Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
The battery
may have
malfunctioned.
NOTE: Depending on the conditions of use and the
ambient temperature, the indication may differ slightly
from the actual capacity.
Switch action
1
1. Switch trigger
CAUTION: Before inserting the battery car-
tridge into the tool, always check to see that the
switch trigger actuates properly and returns to
the "OFF" position when released.
To start the tool, simply pull the switch trigger. Tool
speed is increased by increasing pressure on the switch
trigger. Release the switch trigger to stop.
Lighting up the front lamp
1
1. Lamp
CAUTION: Do not look in the light or see the
source of light directly.
Pull the switch trigger to light up the lamp. The lamp
keeps on lighting while the switch trigger is being pulled.
The lamp goes out 10 -15 seconds after releasing the
trigger.
NOTE: Use a dry cloth to wipe the dirt off the lens of
the lamp. Be careful not to scratch the lens of lamp, or
it may lower the illumination.

Makita DHP482 Specifications

General

Voltage	18V
No Load Speed (High)	0-1, 900 RPM
No Load Speed (Low)	0-600 RPM
Chuck Capacity	13mm
Max. Drilling Capacity in Steel	13mm
Max. Drilling Capacity in Wood	38mm
Max. Drilling Capacity in Masonry	13mm
Max Torque (Soft)	36Nm
Battery Type	Li-ion
Length	198mm
Blows per Minute (High)	0-28, 500 BPM
Blows per Minute (Low)	0 - 9, 000 IPM
Weight	1.5 - 1.8 kg
