ENGLISH (Original instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
Intended use
ENE078-2
The tool is intended for performing lengthways and
crossways straight cuts and mitre cuts with angles in
wood while in firm contact with the workpiece. With
appropriate Makita genuine saw blades, other materials
can also be sawed.
General Power Tool Safety
Warnings
GEA010-1
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and
instructions for future reference.
CORDLESS CIRCULAR SAW
SAFETY WARNINGS
GEB060-8
Cutting procedures
1. DANGER: Keep hands away from cutting area
and the blade. Keep your second hand on
auxiliary handle, or motor housing. If both hands
are holding the saw, they cannot be cut by the blade.
2. Do not reach underneath the workpiece. The guard
cannot protect you from the blade below the
workpiece.
3. Adjust the cutting depth to the thickness of the
workpiece. Less than a full tooth of the blade teeth
should be visible below the workpiece.
4. Never hold piece being cut in your hands or
across your leg. Secure the workpiece to a stable
platform. It is important to support the work properly
to minimize body exposure, blade binding, or loss of
control. (Fig. 1)
A typical illustration of proper hand support and
workpiece support.
5. Hold the power tool by insulated gripping surfaces
only, when performing an operation where the
cutting tool may contact hidden wiring. Contact
with a “live” wire will also make exposed metal parts of
the power tool “live” and could give the operator an
electric shock.
6. When ripping, always use a rip fence or straight
edge guide. This improves the accuracy of cut and
reduces the chance of blade binding.
7. Always use blades with correct size and shape
(diamond versus round) of arbour holes. Blades
that do not match the mounting hardware of the saw
will run eccentrically, causing loss of control.
8. Never use damaged or incorrect blade washers or
bolt. The blade washers and bolt were specially
1. Button
2. Red indicator
3. Battery cartridge
4. Switch trigger
5. Lock-off lever
6. Battery indicator
7. Mode indicator
8. Lever
9. Depth guide
10. Front lever
11. Stopper
12. Cutting line (0° position)
13. Cutting line (45° position)
14. Screw
15. Lamp
16. Hook
17. Close
18. Open
19. Hex wrench
20. Shaft lock
21. Tighten
22. Loosen
23. Inner flange
24. Saw blade
25. Outer flange
26. Hex bolt
27. Mounting shaft
28. Ring
29. Dust nozzle
30. Vacuum cleaner
31. Hose
32. Clamping screw
33. Rip fence (Guide rule)
34. Adjusting screw for 45°
35. Adjusting screw for 0°
36. Triangular rule
37. Bevel guide
38. Guide
Model DHS680
Blade diameter 165 mm
Max. cutting depth
at 0° 57 mm
at 45° 41 mm
at 50° 37 mm
No load speed 5,000 min
-1
Overall length 350 mm
Net weight 3.3 kg
Rated voltage D.C. 18 V

Makita DHS680Z Specifications

General

Power source	Battery
Battery voltage	18 V
Blade diameter	165 mm
Bevel adjustment	-
Idle speed (max)	5000 RPM
Sound power level	94 dB
Cutting depth (45º)	41 mm
Cutting depth (90º)	57 mm
Sound pressure level	83 dB
Sound level uncertainty	3 dB
Quantity	1
Castor wheels	Yes
Uncertainty K	1.5 m/s²
Saw blade type	Single blade
Angle setting type	Stepless
Vibration emission	2.5 m/s²
Angle setting range	0 - 50 °
Product color	Green
Power protection features	Overcharge, Overload

Weight and Dimensions

Depth	170 mm
Width	350 mm
Height	236 mm
Weight	3300 g
Blade thickness	20 mm
