7ENGLISH
For tool with shallow driver bit hole
A=12mm
B=9mm
Use only these type of driver
bit. Follow the procedure
1. (Note) Bit-piece is not
necessary.
For tool with deep driver bit hole
A=17mm
B=14mm
Toinstallthesetypesofdriver
bits, follow the procedure 1.
A=12mm
B=9mm
Toinstallthesetypesofdriver
bits, follow the procedure 2.
(Note) Bit-piece is necessary
for installing the bit.
Procedure 1
For tool without one-touch type sleeve
2
1
1. Driver bit 2. Sleeve
Toinstallthedriverbit,pullthesleeveinthedirectionof
the arrow and insert the driver bit into the sleeve as far
as it will go.
Thenreleasethesleevetosecurethedriverbit.
For tool with one-touch type sleeve
Toinstallthedriverbit,insertthedriverbitintothe
sleeve as far as it will go.
Procedure 2
In addition to Procedure 1, insert the bit-piece into the
sleeve with its pointed end facing in.
123
1. Driver bit 2. Bit-piece 3. Sleeve
Toremovethedriverbit,pullthesleeveinthedirection
of the arrow and pull the driver bit out.
NOTE: If the driver bit is not inserted deep enough
into the sleeve, the sleeve will not return to its original
position and the driver bit will not be secured. In this
case, try re-inserting the bit according to the instruc-
tions above.
NOTE:Whenitisdifculttoinsertthedriverbit,pull
the sleeve and insert it into the sleeve as far as it will
go.
NOTE:Afterinsertingthedriverbit,makesurethatit
isrmlysecured.Ifitcomesout,donotuseit.
Installing hook
2
3
1
1. Groove 2. Hook 3. Screw
Thehookisconvenientfortemporarilyhangingthetool.
Thiscanbeinstalledoneithersideofthetool.Toinstall
the hook, insert it into a groove in the tool housing on
eithersideandthensecureitwithascrew.Toremove,
loosen the screw and then take it out.
OPERATION
Theproperfasteningtorquemaydifferdependingupon
thekindorsizeofthescrew/bolt,thematerialofthe
workpiecetobefastened,etc.Therelationbetweenfas-
teningtorqueandfasteningtimeisshowninthegures.
