10
ENGLISH (Original instructions)
Explanation of general view
1 Red indicator
2Button
3 Battery cartridge
4 Indicator lamps
5 Check button
6 Lock-off button
7 Switch trigger
8 Cutter
9 Guide bar
10 Arrow
11 Spring
12 Sprocket
13 Hook
14 Hole
15 Sprocket cover
16 Knob
17 Oil tank cap
18 Oil inspection window
19 Oil tank opening
20 Tip guide
21 Lower guide
22 Scabbard (chain cover)
23 Push nut
24 Slotted bit screwdriver
25 Filter
26 Locking ring
27 Washer
28 Limit mark
29 Brush holder cap
30 Screwdriver
SPECIFICATIONS
WARNING: Use appropriate combination of the guide bar and saw chain. Otherwise personal injury may result.
Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
Specifications may differ from country to country.
*1: Weight, without the saw chain, guide bar, guide bar cover, oil and battery cartridge(s).
*2: The lightest and heaviest combination of weight, according to EPTA-Procedure 01/2014. The weight may differ
depending on the attachment(s), including the battery cartridge(s).
Applicable battery cartridge and charger
Some of the battery cartridges and chargers listed above may not be available depending on your region of resi-
dence.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges
and chargers may cause injury and/or fire.
Model DUC122
Standard guide bar
Guide bar length 115 mm
Cutting length 11.5 cm
Type Carving bar
Standard saw chain
Type 25 AP
Pitch 6.35 mm (1/4")
Gauge 1.3 mm (0.05")
No. of drive links 42
Sprocket
Number of teeth 9
Pitch 6.35 mm (1/4")
Overall length 422 mm
Net weight
*1 1.7 kg
*2 2.4 - 2.7 kg
Chain speed per minute (min
–1
) 5.0 m/s (300 m/min)
Chain oil tank volume 80 cm
3
Rated voltage D.C. 18 V
Battery cartridge
BL1815N / BL1820B / BL1830B / BL1840B / BL1850B /
BL1860B
Charger
DC18RC / DC18RD / DC18RE / DC18SD / DC18SE /
DC18SF / DC18SH
