15 ENGLISH
Storage
The hook hole in the tool bottom is convenient for hang-
ing the tool from a nail or screw on the wall.
Attach the blade cover to the shear blades so that the
blades are not exposed. Store the tool out of the reach
of children. Store the tool in a place not exposed to
moisture or rain.
► Fig.33: 1. Hole
Grinding the shear blades
NOTICE: If the shear blades have considerably
deformed by grinding, replace the shear blades
with new ones.
1. Install the battery cartridge to the tool.
2. Turn on and start the tool so that the upper blade
and lower blade are positioned alternately.
► Fig.34
3. Turn off the tool and remove the battery cartridge
from the tool.
4. Remove the screw, and then remove the tip guard.
► Fig.35: 1. Screw 2. Tip guard
5. Set the angle of a le to 45°, and grind the upper
blade from 3 directions with the le.
► Fig.36: (1) File (2) 45°
CAUTION: Before grinding the shear blades,
make sure that the tool is switched off and the
battery cartridge is removed from the tool.
6. Place the tool upside down, and then remove the
burrs from the shear blades with the le.
► Fig.37: 1. File
7. Set the angle of the le to 45°, and grind the lower
blade from 3 directions with the le.
8. Return the tool to normal position, and then
remove the burrs from the shear blades with the le.
9. Attach the tip guard by tightening the screw.
Grease lubrication
Interval of lubrication: Every 100 operating hours
1. Remove 3 screws, and then remove the bottom
cover.
► Fig.38: 1. Screw 2. Bottom cover
2. Remove the cap from the grease vessel, and then
attach the grease vessel to the hole on the cover by
turning the grease vessel.
► Fig.39: 1. Cover 2. Grease vessel
3. Apply the grease to the tool (Approximately 5 g as
a guide).
4. Remove the grease vessel.
5. Attach the bottom cover, and then tighten 3
screws.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual. The use of any other
accessories or attachments might present a risk of
injury to persons. Only use accessory or attachment
for its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• Shear blade assembly
• Shear blade cover
• Chip receiver
• Grease vessel
• Makita genuine battery and charger
NOTE: Some items in the list may be included in the
tool package as standard accessories. They may
differ from country to country.
