Makita DUR188L User Manual

6 ENGLISH
PARTS DESCRIPTION
1
1
2
3
4
4
2
3
5
5
6
6
8
9
11 12
13
14 15
7
7
10
8
9
10
16
16
6
6
1 Battery cartridge 2 Lock-off lever 3 Switchtrigger 4 Hanger
5 Handle 6 Protector (cutting tool
guard)
7 Wireguard 8 Lock lever
(DUR188Uand
DUR188Lonly)
9 Joint cover
(DUR188Uand
DUR188Lonly)
10 Cap
(DUR188Uand
DUR188Lonly)
11 Speedindicator 12 Auto speed control
indicator
13 Power lamp 14 Mainpowerbutton 15 Reverse button 16 Shoulderharness
* The shape of the protector varies depending on the country.
