Makita DUR368AZ User Manual

18 ENGLISH
To remove the plastic blade, follow the installation pro-
cedures in reverse.
OPERATION
Attaching the shoulder harness
CAUTION: Always use the shoulder harness
attached to the tool. Before operation, adjust the
shoulder harness according to the user size to
prevent fatigue.
CAUTION: Before operation, make sure that
the shoulder harness is properly attached to the
hanger on the tool.
1. Wear the shoulder harness on your left shoulder.
2. Clasp the hook on the shoulder strap to tool's
hanger.
DUR368A
1
2
►1. Hook 2. Hanger
DUR368L
1
2
►1. Hook 2. Hanger
3. Adjusttheshoulderharnesstoacomfortable
working position.
The shoulder harness features a means of quick
release.
Simply squeeze the sides of the buckle to release the
tool from the shoulder harness.
DUR368A
1
►1. Buckle

Makita DUR368AZ Specifications

General

Power source	Battery
Battery voltage	18 V
Removable battery	Yes
Type	String trimmer
Head type	Nylon line
Handle type	U-type handle
Rotational speed	6500 RPM
Sound power level	89 dB
Vibration emission	2.5 m/s²
Sound pressure level	76.4 dB
Cutting diameter (max)	- mm
Sound pressure level uncertainty	1.6 dB

Weight and Dimensions

Weight	4100 g
