Makita DUR369LZ User Manual

13 ENGLISH
Speed adjusting
You can select the tool speed by tapping the main
power button. Each time you tap the main power button,
the level of speed will change. The tool automatically
adjuststherotationspeedaccordingtothecuttingtool
attached to the tool.
2
1
►1. Speed indicator 2. Main power button
Speed
indicator
Mode Rotation speed
Cutter blade
Plastic blade
(305 mm)
Nylon cutting
head
Plastic blade
(255 mm)
High 0 - 7,000
min
-1
0 - 5,500
min
-1
Medium 0 - 5,500
min
-1
0 - 5,000
min
-1
Low 0 - 4,600
min
-1
0 - 4,600
min
-1
Automatic Torque Drive Technology
When you turn on the Automatic Torque Drive
Technology (ADT), the tool runs at optimum rotation
speed and torque for the condition of grass being cut.
The tool automatically detects the cutting tool attached
and chooses a suitable rotation speed.
To start ADT, press and hold the reverse button until the
ADT indicator turns on.
To stop ADT, press and hold the reverse button until the
ADTindicatorturnso󰀨.
2
1
►1. ADT indicator 2. Reverse button
Indicator Mode Cutting tool Rotation
speed
ADT Cutter blade
Plastic blade
(305 mm)
3,500 - 7,000
min
-1
Nylon cutting
head
Plastic blade
(255 mm)
3,500 - 5,500
min
-1
Reverse button for debris removal
WARNING: Switch o󰀨 the tool and remove
the battery cartridge before you remove entan-
gled weeds or debris which the reverse rotation
function can not remove.Failuretoswitcho󰀨and
remove the battery cartridge may result in serious
personalinjuryfromaccidentalstart-up.
This tool has a reverse button to change the direction of
rotation. It is only for removing weeds and debris entan-
gled in the tool.
To reverse the rotation, tap the reverse button and pull
theswitchtriggerwhiledepressingthelock-o󰀨lever
when the cutting tool is stopped. The speed indicators
and ADT indicator start blinking, and the cutting tool
rotates in reverse direction when you pull the switch
trigger.
To return to regular rotation, release the trigger and wait
until the cutting tool stops.
3
2
1
►1. Speed indicator 2. ADT indicator 3. Reverse
button

Makita DUR369LZ Specifications

General

Type	2-in-1 Brush cutter & String trimmer
Cordless	Yes
Head type	Blade & nylon line
Handle type	D-loop handle
Product color	Green
Rotational speed	7000 RPM
Cutting diameter (max)	430 mm
Power source	Battery
Battery voltage	18 V
Battery included	No

Weight and Dimensions

Length	1905 mm
Weight	5700 g
