Makita EA7900P User Manual

18
Denomination of components
1 Handle
2 Filter cover
3 Filter hood clip
4 Tubular handle
5 Hand guard (release for chain brake)
6 Mufer with spark arrester screen
7 Spike bar (toothed stop for holding saw
steady against wood)
8 Chain tensioning screw
9 Retaining nuts
10 Chain catch
11 Sprocket guard
12 Identication plate
13 Decompression valve
14 Starter grip
15 Adjusting screws "S-L-H" for carburetor
16
I/STOP-switch
17 Choke lever
18 Throttle lever
19 Throttle stopper
20 Hand guard
21 Fuel tank cap
22 Fan housing with starting assembly
23 Oil tank cap
24 Guide bar
25 Chain
26 Adjusting screw for oil pump (bottom side)
Indicate when ordering spare parts!
Identicationplate
Serial no.
Year of manufacture
EA7900P
445.060.655
038.100.650 Typ 038
528.099.684
Makita Corporation, Anjo, Aichi, Japan
Made in Germany
24" (600mm)
2013.06 123456
2 3 41
6
7
5
8
9
1126
12
10
13
25
14 15
16 17
18 19
2324
202122
