19
WARNING:
This chain saw is capable of severe kickback that coult result in serious injury to the user. Do not operate this chain
saw unless you have extraordinary cutting needs and experience and specialized training for dealing with kickback.
Chain saws with signicantly reduced kickback potential are available.
Technical data
Stroke volume cu. in (cm
3
)
4.4 (72.6) 4.8 (78.5)
Bore inch (mm) 1.97 (50) 2.04 (52)
Stroke inch (mm) 1.45 (37) 1.45 (37)
Max. power at speed hp / rpm 5.4 / 10,000 5.7 / 10,000
Max. torque at speed Nm / rpm 4.5 / 7,000 4.7 / 7,000
Limit speed with guide bar and chain rpm 12,800 12,800
Idling speed rpm 2,500 2,500
Coupling speed rpm 3,200 3,200
Sound Pressure Level at the operator‘s ear
at full load according to ANSI B 175.1 db(A) 101.4 101.4
Sound Pressure Level at the bystander‘s position
(50 ft/15 m distance) according to ANSI B 175.1 db(A) 78.7 78.7
Carburetor (diaphragm carburetor) Type ZAMA
Ignition system Type electronic
Spark plug Type NGK BPMR 7A
Electrode gap inch (mm) .020 (0.5)
or spark plug Type BOSCH WSR-6F
Fuel consumption at max. load per ISO 7293 kg/h 1.9 2.0
Specic consumption at max. load per ISO 7293 g/kWh 460 460
Fuel tank capacity oz 25.36
Chain oil tank capacity oz 14.20
Mixture ratio (fuel/two-stroke oil)
- when using MAKITA synthetic oil 50:1
- when using other synthetic oils
(oil quality must be JASO FC or ISO-L-EGD)
50:1
Chain brake engages manually or in case of kickback
Sprocket pitch inch 3/8
Number of teeth Z 7
Chain type (see the Extract from the spare-parts list) 099
Pitch / Driving element strength inch 3/8 / .058
Guide bar, length of a cut inch 15 / 18 / 20 / 24 / 28
Guide-bar type (see the Extract from the spare-parts list)
Weight (fuel tank empty, without chain and guide bar) lbs 14.7 14.7
EA7300P EA7900P
