7
TECHNICAL DATA
Model EH7500S
Dimension (L x W x H) mm 1,150 x 323 x 212
Mass (without blade cover) kg 4.7
Volume (fuel tank) L 0.4
Engine displacement cm
3
22.2
Cutting length mm 728
Maximum engine performance kW 0.68
Maximum blade speed min
-1
4,390
Idling speed min
-1
3,000
Clutch engagement speed min
-1
4,000
Carburetor type type WALBRO WYL
Ignition system type Solid state ignition
Spark plug type NGK CMR6A
Electrode gap mm 0.7 - 0.8
Vibration per
ISO 10517
Right handle
a
hv eq
m/s
2
3.2
Uncertainty K m/s
2
0.25
Left handle
a
hv eq
m/s
2
3.5
Uncertainty K m/s
2
0.52
Sound pressure level average according to ISO 10517 dBA 94.3
Sound power level according to ISO 10517 dBA 101.8
Mixture ratio (fuel: MAKITA 2-stroke engine oil) 50 : 1
Gear ratio 9 : 43
1) The data takes equally into account the idling and racing speed operating modes.
EC-DECLARATION OF CONFORMITY
Petrol Hedge Trimmer: model EH7500S
(See TECHNICAL DATA for the specications)
We declare under our sole responsibility that this product is in compliance with the following Directives, 2000/14/EC, 2006/42/EC.
The most important standards applied to properly meet the requirements of the above Directives were: ISO 10517.
Measured Sound Power: 102.7 dB (A)
Guarantee Sound Power: 105 dB (A)
These sound power levels wear measured in accordance with Council Directive, 2000/14/EC.
Conformity assessment procedure: Annex V.
19. FEB. 2010
Tomoyasu Kato
Director
Responsible Manufacturer:
Makita Corporation.
3-11-8, Sumiyoshi-cho, Anjo, Aichi, JAPAN
Authorized Representative in Europe:
Makita International Europe Ltd.
Michigan Drive, Tongwell, Milton Keynes, Bucks MK15 8JD, ENGLAND
