Bezeichnung der Bauteile
1 Gasseilzug
2 Entriegelungshebel
3 Gashebel
4 Stoppschalter
5 Griff
6 Achse
7 Getriebe
8 Schneidmesser
9 
10 Kraftstoff-Tankdeckel
11 Kraftstofftank
12 Kupplungsgehäuse
13 Zündkerzenstecker
14 Anlasseinspritzpumpe
15 Schalldämpfer
16 Seilzugstarter
17 Startergriff
18 Schneidblattschutz
19 
20 
21 Umhängeriemen
(optionales Zubehör)
