Makita ER2650LH User Manual

11
Observe the applicable accident prevention regulations!
STARTING
Move at least 3 m away from the place of refueling. Place the unit on the ground taking care that the cutting attachment does not come into
contact with the ground or any other objects.
A: Cold start
1) Setthismachineonaatspace.
2) Set the I-O switch (1) to OPERATION.
OPERATION
Lock-off lever
High speed
Low speed
Throttle lever
POINTS IN OPERATION AND HOW TO STOP
STOP
(1)
3) Primer pump
Continue to push the primer pump until fuel enters into the primer pump. (In
general, fuel enters into the primer pump by 7 to 10 pushes.)
If the primer pump is pushed excessively, an excess of gasoline returns to
the fuel tank.
NOTE:Incaseofexcessivefuelintake(ooding),removethesparkplugandpullthestarterhandleslowlytoremoveexcessfuel.Also,drythe
electrode section of the spark plug.
B: Startup after warm-up operation
1) Push the primer pump repeatedly.
2) Keep the throttle lever at the idling position.
3) Pull the recoil starter strongly.
4) Ifitisdifculttostarttheengine,openthethrottlebyabout1/3.
Carburetor
Primer Pump
4) Recoil starter
Pull the start knob gently until it is hard to pull (compression point). Then,
return the start knob, and pull it strongly.
Never pull the rope to the full. Once the start knob is pulled, never release
your hand immediately. Hold the start knob until it returns to its original
point.
5) Warm-up operation
Continue warm-up operation for 2 to 3 minutes.

Makita ER2650LH Specifications

General

Power source	Gasoline
Cordless	Yes
Product color	Black, Cyan
Cutting diameter (max)	412 mm

Weight and Dimensions

Weight	4800 g
