Inspectionandrellofengineoil
Perform the following procedure, with the engine cooled down. –
Set the engine level, remove oil cap (Fig. 1), and check to see whether or not there is oil in the range between the upper limit and lower limit –
marks of the oil pipe (Fig. 2).
Fillwithoiltoupperlimitmarkifoilisinsufcient(oillevelisclosetolowerlimitmark)(Fig.3). –
The area surrounding the external marks is transparent, so the amount of oil inside can be checked without having to remove the oil cap. –
However, if oil pipe becomes extremely dirty, visibility may be lost, and oil level will have to be checked against stepped section on inside of
oil pipe.
Forreference,theoilrelltimeisabout10h(10timesor10reservoirsofgasbeforeoilneedstoberelled). –
If the oil changes in color or mixes with dirt, replace it with new one. (For the interval and method of replacement, refer to P 14)
Recommended oil: SAE10W30oilofAPIClassication,ClassSForhigher(4strokeengineforautomobile)
Oil volume: Approx. 0.08L
NOTE: If the engine is not kept upright, oil may pool in other parts of the engine. The oil levelgauge may give an incorrect reading for oil level.
Donotllwithoilifengineisnotupright.Iftheoilislledabovethelimit,theoilmaybecontaminatedormaycatchrewithwhite
smoke.
Point 1 in Replacement of oil: “Oil cap”
Removedustordirtneartheoilrellport,anddetachtheoilcap. –
Keep the detached oil cap free of sand or dust. Otherwise, any sand or dust adhering to the oil cap may cause irregular oil circulation or –
wear on the engine parts, which will result in troubles.
Fig. 1
Fig. 2 Oil pipe Fig. 3
BEFORE START OF OPERATION
(1) Keep the engine level, and detach the oil cap.
Oil cap
Oil pipe
Internal stepped
section (upper
limit)
External mark
(lower limit)
Internal stepped
section (lower
limit)
External mark
(upper limit)
Oil
Top up with oil until
oil level reaches
internal stepped
section (upper
limit).
The area between the
external upper and lower
limits is transparent, so
oil level can be checked
externally against these
marks.
(2) Fill with oil to upper limit mark. (see Fig. 3)
 Useoilbottlewhenlling.
(3) Securelytightentheoilcap.Insufcienttighteningmaycauseoilleakage.
