Makita GD0600 User Manual

7
Turn the tool on without the wheel point making any
contact with the workpiece and wait until the wheel point
attains full speed. Then apply the wheel point to the
workpiece gently. To obtain a good finish, move the tool
in the leftward direction slowly.
CAUTION:
• Apply light pressure on the tool. Excessive
pressure on the tool will only cause a poor finish
and overloading of the motor.
MAINTENANCE
CAUTION:
• Always be sure that the tool is switched off and
unplugged before attempting to perform inspection
or maintenance.
To maintain product SAFETY and RELIABILITY, repairs,
carbon brush inspection and replacement, any other
maintenance or adjustment should be performed by
Makita Authorized Service Centers, always using Makita
replacement parts.
ACCESSORIES
CAUTION:
• These accessories or attachments are
recommended for use with your Makita tool
specified in this manual. The use of any other
accessories or attachments might present a risk of
injury to persons. Only use accessory or
attachment for its stated purpose.
If you need any assistance for more details regarding
these accessories, ask your local Makita Service Center.
Side handle
1
007054
When using the side handle, remove the rubber
protector, insert the side handle on the tool barrel as far
as it will go and rotate it to the desired angle. Then
tighten the handle firmly by turning clockwise.
CAUTION:
• When using the tool without handle, always install
the rubber protector on the tool.
• When installing the rubber protector, always push it
onto the tool until the protrusion inside the rubber
fits to the grooves in the tool.
• Wheel points
• Collet cone set (3 mm, 6 mm, 1/4", 1/8")
• Wrench 13
• Side handle set
• Vise holder
1. Side handle

Makita GD0600 Specifications

General

Input power	400 W
Power source	AC
Idle speed (max)	25000 RPM
Vibration level (grinding)	2.5 m/s²
Product color	Blue
Noise level	73 dB
Maximum diameter of grinding tool	6 mm

Weight and Dimensions

Depth	358 mm
Width	82 mm
Weight	1600 g
