Makita HM0871C User Manual

7
010490
After installing, always make sure that the bit is securely
held in place by trying to pull it out.
1
010491
To remove the bit, pull the releasing cover down all the
way and pull the bit out.
Bit angle
1
010492
010493
The bit can be secured at 12 different angles. To change
the bit angle, slide the change ring forward, then turn the
change ring to change the bit angle. At the desired angle,
slide the change ring back to the original position. The
bit will be secured in place.
NOTE:
• The change ring cannot turn when the bit is not
installed on the tool.
OPERATION
Chipping/Scaling/Demolition
010495
010455
Always use the side grip (auxiliary handle) and firmly
hold the tool by both side grip and switch handle during
operations. Turn the tool on and apply slight pressure on
the tool so that the tool will not bounce around,
uncontrolled. Pressing very hard on the tool will not
increase the efficiency.
MAINTENANCE
CAUTION:
• Always be sure that the tool is switched off and
unplugged before attempting to perform inspection
or maintenance.
• Never use gasoline, benzine, thinner, alcohol or
the like. Discoloration, deformation or cracks may
result.
Lubrication
CAUTION:
• This servicing should be performed by Makita
Authorized Service Centers only.
This tool requires no hourly or daily lubrication because
it has a grease-packed lubrication system. It should be
lubricated every time the carbon brushes are replaced.
Send the complete tool to Makita Authorized Service
Center for this lubrication service.
1. Change ring
1. Releasing cover

Makita HM0871C Specifications

General

Input power	1100 W
Impact energy (max)	8.1 J
Vibration level (chiseling)	8 m/s²
Toolholder	18 mm
Impact rate	2650 bpm
Product color	Black, Blue

Weight and Dimensions

Depth	116 mm
Width	466 mm
Height	230 mm
Weight	5600 g
