Makita HM1307CB Instruction Mamual

3
ENGLISH (Original instructions)
Explanation of general view
1-1. Switch lever
2-1. Adjusting dial
3-1. Power-ON indicator lamp (green)
3-2. Service indicator lamp (red)
4-1. Set bolt
4-2. Nut
4-3. Side handle
5-1. Bit
5-2. Tool retainer
5-3. Tool holder
6-1. Bit with collar
6-2. Bit without collar
8-1. Rear cover
8-2. Hex wrench
9-1. Crank cap
10-1. Hammer grease
11-1. Rear cover
11-2. Hex wrench
12-1. Crank cap cover
13-1. Hammer grease
SPECIFICATIONS
Model HM1317C HM1307C HM1317CB HM1307CB
Blows per minute 730 - 1,450
Overall length 715 mm 824 mm
Net weight 17.0 kg 15.3 kg 19.0 kg 17.3 kg
Safety class /II
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Note: Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
ENE045-1
Intended use
The tool is intended for chiselling work in concrete, brick,
stone and asphalt as well as for driving and compacting
with appropriate accessories.
ENF002-2
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated and can, therefore, also be used
from sockets without earth wire.
ENG905-1
Noise
The typical A-weighted noise level determined according
to EN60745:
Model HM1307,HM1317C
Sound pressure level (L
pA
) : 81 dB(A)
Sound power level (L
WA
) : 101 dB(A)
Uncertainty (K) : 3 dB(A)
Model HM1307CB
Sound pressure level (L
pA
) : 81 dB(A)
Sound power level (L
WA
) : 101 dB(A)
Uncertainty (K) : 2.35 dB(A)
Model HM1317CB
Sound pressure level (L
pA
) : 81 dB(A)
Sound power level (L
WA
) : 101 dB(A)
Uncertainty (K) : 3.07 dB(A)
Wear ear protection
ENG900-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745:
Model HM1307C
Work mode : chiseling function with side handle
Vibration emission (a
h,CHeq
) : 12.5 m/s
2
Uncertainty (K) : 2.0 m/s
2
Model HM1307CB
Work mode : chiseling function with side handle
Vibration emission (a
h,CHeq
) : 12.0 m/s
2
Uncertainty (K) : 1.5 m/s
2
Model HM1317C
Work mode : chiseling function with side handle
Vibration emission (a
h,CHeq
) : 8.5 m/s
2
Uncertainty (K) : 1.5 m/s
2
Model HM1317CB
Work mode : chiseling function with side handle
Vibration emission (a
h,CHeq
) : 7.0 m/s
2
Uncertainty (K) : 1.5 m/s
2

Makita HM1307CB Specifications

General

Chuck type	-
Product color	Black, Blue
Sound power level	101 dB
Impact energy (max)	34.9 J
Vibration level (chiseling)	12 m/s²
Input power	- W
Power source	AC

Weight and Dimensions

Weight	17327 g
