Makita LM001G User Manual

10 ENGLISH
Removing the mulching plug
1. Open the rear cover.
1
Fig.4
► 1. Rear cover
2. Lift up the mulching plug slightly, and then remove
it.
1
Fig.5
► 1. Mulching plug
Assembling the grass basket
1. Pick up the upper clip of the grass basket.
1
Fig.6
► 1. Upper clip
2. Insert the frame into the grass basket as far as it
will go while holding the handle of the frame.
1
Fig.7
► 1. Handle
NOTICE: Do not insert the handle into the grass
basket. Be sure to insert the frame along the stitch of
the grass basket.
3. Make sure that there is no sagging on the corners
of the grass basket.
Fig.8
4. Open the upper clip, and attach it to the frame.
Fig.9

Makita LM001G Specifications

General

Brand	Makita
Model	LM001G
Category	Lawn Mower
Language	English
