Makita LS1018LN User Manual

11
ENGLISH (Original Instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2014
1. Stopper pin
2. Bolts
3. Holder
4. Holder assembly
5. Screw
6. Blade guard
7. Kerf board
8. Saw blade
9. Blade teeth
10. Left bevel cut
11. Straight cut
12. Right bevel cut
13. Adjusting bolt
14. Turn base
15. Top surface of turn base
16. Periphery of blade
17. Guide fence
18. Stopper arm
19. Adjusting screw
20. Miter scale
21. Pointer
22. Lock lever
23. Grip
24. Lever
25. Arm
26. Bevel scale
27. Release button
28. Locking screw
29. Lock-off button
30. Switch trigger
31. Hole for padlock
32. Switch for laser
33. Screw holding the laser unit box
34. Dry cell
35. Socket wrench with hex wrench
on its other end
36. Wrench holder
37. Socket wrench
38. Blade case
39. Center cover
40. Hex bolt
41. Arrow
42. Shaft lock
43. Hex bolt (left-handed)
44. Outer flange
45. Ring
46. Inner flange
47. Spindle
48. Dust nozzle
49. Dust bag
50. Fastener
51. Support
52. Sliding fence
53. Clamping screw
54. Sub-fence R
55. Screws
56. Vise arm
57. Vise knob
58. Vise rod
59. Vise plate
60. Vise nut
61. 52/38° type crown molding
62. 45° type crown molding
63. 45° type cove molding
64. Inside corner
65. Outside corner
66. Vise
67. Spacer block
68. Aluminum extrusion
69. Horizontal vise (optional
accessory)
70. Holes
71. Cut grooves with blade
72. Triangular rule
73. 0° adjusting bolt
74. Left 45° bevel angle adjusting bolt
75. Top surface of turn table
76. Right 45° bevel angle adjusting
bolt
77. Screwdriver
78. Brush holder cap
Model LS1018 LS1018L
Blade diameter 255 - 260 mm
Hole diameter
Countries other than Europe
25.4 mm or 30 mm
(country specific)
European countries 30 mm
Max. kerf thickness of the saw blade 3.2 mm
Max. miter angle Right 60°, Left 47°
Max. bevel angle Right 45°, Left 45°
No load speed (RPM) 4,300 min
-1
Laser type –
Red Laser 650 nm,
Maximum output
1 mW < ( Laser Class 2M )
Dimensions (L x W x H) 825 mm x 536 mm x 633 mm
Net weight 21.5 kg
Safety class /II

Makita LS1018LN Specifications

General

Product type	Sliding compound-miter saw
Blade bore	30 mm
Blade diameter	260 mm
Idle speed (max)	4300 RPM
Bevel setting (left)	45 °
Sound pressure level	94 dB
Sound level uncertainty	3, 103 dB
Bevel type	-
Input power	1430 W
Power source	AC

Weight and Dimensions

Weight	20600 g
