11 ENGLISH
Whenthecut-o󰀨wheelhasworndown,raisethecutting
positionbyputtingaspacerblockwhichisslightlynar-
rowerthantheworkpieceasshowninthegure.This
willhelpyoutoutilizethecut-o󰀨wheeleconomically.
►Fig.16: 1. Vise plate 2. Workpiece diameter
3. Guide plate 4.Spacerblockwidth
Longworkpiecesmustbesupportedbyblockson
eithersidesothatitwillbelevelwiththebasetop.Use
non-ammablematerialforsupportingblocks.
►Fig.17: 1.Supportingblock
Carrying tool
Folddownthetoolheadandlockit.Holdthehandle
when carrying.
►Fig.18
MAINTENANCE
CAUTION: Always be sure that the tool is
switched o󰀨 and unplugged before attempting to
perform inspection or maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
Replacing carbon brushes
►Fig.19: 1. Limit mark
Checkthecarbonbrushesregularly.
Replace them when they wear down to the limit mark.
Keepthecarbonbrushescleanandfreetoslipinthe
holders.Bothcarbonbrushesshouldbereplacedatthe
sametime.Useonlyidenticalcarbonbrushes.
1. Useascrewdrivertoremovethebrushholder
caps.
2. Takeouttheworncarbonbrushes,insertthenew
onesandsecurethebrushholdercaps.
►Fig.20: 1. Brush holder cap
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
beperformedbyMakitaAuthorizedorFactoryService
Centers,alwaysusingMakitareplacementparts.
