11 ENGLISH
Switch action
WARNING: Before installing the battery car-
tridge into the tool, always check to see that the
switch trigger actuates properly and returns to
the "OFF" position when released.
WARNING:
by taping down or some other means. A switch with
WARNING: NEVER use the tool if it runs when
you simply pull the switch trigger without press-
A switch in need of repair
for proper repairs BEFORE further usage.
CAUTION: The tool starts to brake the cir-
cular saw blade rotation immediately after you
respond the reaction of the brake when releasing
the switch trigger. Sudden reaction can drop the tool
Release the switch trigger to stop.
Fig.13: 1. Switch trigger 2.
NOTICE: Do not pull the switch trigger hard
This can
cause switch breakage.
Electric brake
This tool is equipped with an electric blade brake. If the
blade after switch lever release, have tool serviced at a
Makita service center.
CAUTION: The blade brake system is not a
substitute for blade guard. NEVER USE TOOL
WITHOUT A FUNCTIONING BLADE GUARD.
SERIOUS PERSONAL INJURY CAN RESULT.
Electronic function
Soft start feature
Soft start because of suppressed starting shock.
ASSEMBLY
CAUTION: Always be sure that the tool is
before carrying out any work on the tool.
Fig.14: 1.
Removing or installing circular saw blade
CAUTION:
Be sure the circular saw blade is
installed with teeth pointing up at the front of the tool.
CAUTION:
to install or remove the circular saw blade.
wrench to loosen the hex bolt. Then remove the hex bolt,
Fig.15: 1. Shaft lock 2.3. Loosen
4. Tighten
For tool without the ring
Fig.16: 1. Hex bolt 2.3. Circular saw
blade 4. Arrow on the circular saw blade
5.6. Arrow on the tool
For tool with the ring
Fig.17: 1. Hex bolt 2.3. Circular saw
blade 4. Arrow on the circular saw blade
5. Ring 6.7. Arrow on the tool
To install the circular saw blade, follow the removal
procedure in reverse.
Align the direction of the arrow on the circular saw blade
with the arrow on the tool.
than 15.88 mm hole-diameter saw blade
other side. Choose a correct side on which protrusion
Fig.18: 1. Mounting shaft 2.3. Circular
saw blade 4.5. Hex bolt
WARNING: BE SURE TO TIGHTEN THE HEX
BOLT COUNTERCLOCKWISE SECURELY. Also
be careful not to tighten the bolt forcibly. Slipping
your hand from the hex wrench can cause a per-
sonal injury.
WARNING: Make sure that the protrusion "a"
into the saw blade hole "a" perfectly. Mounting the
circular saw blade on the wrong side can result in the
dangerous vibration.
