Makita UC3541A User Manual

2
ENGLISH (Original instructions)
SPECIFICATIONS
Model UC3041A UC3541A UC4041A
Max. chain speed 14.5 m/s (870 m/min)
Bar length 300 mm 350 mm 400 mm
Cutting length 265 mm 325 mm 360 mm
Standard guide bar
Guide bar type Sprocket nose bar
Type 90PX 91PX 90PX 91PX 90PX 91PX
Pitch 3/8"
Standard saw chain
No. of drive links 46 52 56
Recommended guide bar length 300 - 400 mm
Overall length (without guide bar) 455 mm
Net weight 4.6 kg 4.7 kg 4.7 kg
Extension cable (optional) DIN 57282/HO 7RN -F L=30 m max.,3x1.5 mm
2
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
END218-7
Symbol
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･ Read instruction manual and follow the
warnings and safety instructions.
･ Wear eye protection.
･ Wear ear protection.
･ DOUBLE INSULATION
･ Caution: particular care and attention
required!
･ Caution: withdraw the mains plug
immediately if the cable is damaged!
･ Caution: kickback!
･ Protect against rain and damp!
･ Wear a helmet, goggles and ear
protection!
･ Wear safety gloves!
･ Withdraw the mains plug!
･ First aid
･ Maximum permissible length of cut
･ Direction of chain travel
･ Chain oil
･ Chain brake released
･ Chain brake applied
･ Prohibited!
･ Only for EU countries
Do not dispose of electric equipment
together with household waste
material!
In observance of the European
Directive, on Waste Electric and
Electronic Equipment and its
implementation in accordance with
national law, electric equipment that
have reached the end of their life must
be collected separately and returned to
an environmentally compatible
recycling facility.
ENE085-1
Intended use
The tool is intended for cutting lumbers and logs.
ENF002-2
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated and can, therefore, also be used
from sockets without earth wire.
ENF100-1
For public low-voltage distribution systems of
between 220 V and 250 V.
Switching operations of electric apparatus cause
voltage fluctuations. The operation of this device under
unfavorable mains conditions can have adverse effects

Makita UC3541A Specifications

General

Power source	AC
Idle speed	7820 RPM
Chain gauge	1.27 mm
Chain pitch	3/8 \
Chain speed	14.5 m/s
Blade length	325 mm
Product color	Black, Turquoise
Automatic oiling	Yes
Chain bar length	350 mm
Oil tank capacity	0.2 L
Noise level	101.3 dB
Uncertainty K	1.5 m/s²
Standard deviation	2.5 dB
Vibration emission	4.3 m/s²
Sound pressure level	90.3 dB

Weight and Dimensions

Width	245 mm
Height	200 mm
Length	455 mm
Weight	4700 g
