8 ENGLISH
Adjusting the shoulder strap
1
3
2
1. Pull out 2. For shortening 3. For extending
To adjust the length of the shoulder strap, pull it out to
your desired length and pull the strap in the direction of
arrow as shown in the gure.
Connecting the hose
CAUTION:
Do not force the hose to bend it and/or
stamp it. Forcing and/or stamping the hose may
cause deformation or damage to the hose.
Do not pull the hose to carry the cleaner.
Pulling the hose may cause deformation or
damage to the hose.
1
2
A
B
1. Dust outlet 2. Power tool
Insert the "A" end of the hose to the suction opening
of the cleaner and turn it clockwise all the way until it
locks.
Attach the cuff on the "B" end of the hose and then
connect it to the dust outlet of an power tool.
Replacing the front cuff
Change the front cuff of the hose according to the dust
outlet size of a power tool you use.
1
2
3
4
1. Front cuff 2. Hose 3. Remove 4. Install
To remove the front cuff, hold the hose and turn it counterclockwise.
To mount the front cuff, turn it clockwise and then screw
it in until it stops.
OPERATION
WARNING:
Do not use the shoulder strap when working in a high place.
When using the cleaner as a stationary cleaner,
place it on a at and stable surface.
