Technical data
32
Model D 0824 LE 201
Design in-line vertical
Cycle 4-stroke Diesel with turbocharger and
intercooler
Combustion system Direct injection
Turbocharging Turbocharger with intercooler
Number of cylinders 4
Bore 108 mm
Stroke 125 mm
Swept volume 4 580 cm
3
Compression ratio 16,5 : 1
Rating see engine nameplate
Firing order 1–3–4–2
Valve clearance (cold engine)
Intake 0.50 mm
Exhaust 0.50 mm
Valve timing
Intake opens 6° before TDC
Intake closes 32°% after BDC
Exhaust opens 63°% before BDC
Exhaust closes 13°% after TDC
Fuel system
Injection pump distributor-type injection pump
Governor Electronic speed control (GAC)
Start of delivery
1500 rpm 0°±0,5° before TDC
1800 rpm 0°±0,5° before TDC
Injectors four-hole nozzles
Opening pressure of injector:
New nozzle holder: 265+8 bar
Used nozzle holder: 250+8 bar
Fuel filter Parallel box-type filter
