Manitou E-E3 Series User Manual

2-13
HYDRAULIC MOVEMENTS
Longitudinal stability limiter and warning device Electronic
Lifting motions (boom retracted)
Unladen lifting s - m/mn 7,2 - 37,6
Laden lifting s - m/mn 7,2 - 37,6
Unladen lowering s - m/mn 5,5 - 49,2
Laden lowering s - m/mn 5,8 - 46,6
Telescoping motions (boom raised)
Unladen extending s - m/mn 6,5 - 24,9
Laden extending s - m/mn 6,5 - 24,9
Unladen retracting s - m/mn 5,4 - 30,0
Laden retracting s - m/mn 5,9 - 27,5
Tilting movements
Unladen digging s - °/s 2,9 - 43,3
Forward tilting unladen s - °/s 2,8 - 44,9
SPECIFICATIONS AND WEIGHTS
Speed of movement for lift truck in standard configuration on flat
ground (except particular conditions)
Front unladen 1 km/h 4,4
2 km/h 7,1
3 km/h 15,0
4 km/h 26,7
Rear unladen 1 km/h 4,4
2 km/h 7,1
3 km/h 15,0
4 km/h 26,7
Standard attachment TFF
Weight of equipment kg 165
Weight of forks (each one) kg 67,5
Rated capacity with standard attachment kg 3200
Tipping load at maximum reach on tyres kg 1620
Distance from the centre of gravity from the load to the lug of the forks mm 500
Standard lifting height mm 6900
Lift truck weight without attachment kg 7030
Lift truck weight with standard attachment
Unladen kg 7330
At rated load kg 10530
Weight per axle with standard attachment (transport position)
Front unladen kg 3160
Rear unladen kg 4170
Front rated load kg 9060
Rear rated load kg 1470
Weight per axle with standard attachment (boom extended)
Front rated load kg 7830
Rear rated load kg 750
Authorised gross vehicle weight daN 23330
Contact pressure on the ground for the whole surface of each stabilizer
at maximum load when tilting
kg/cm2 -
Drag strain on the coupling hook
Unladen (sliding) daN 6155
At rated load (transmission setting) daN 9280
Pull strain with open carrier (according to standard ISO 8313) daN 7400
HYDRAULIC CIRCUIT
Hydraulic pump
Type Gear type with flow divider
Capacity cm3 1st chamber 2nd chamber
Max. rating capacity unladen l/mn 22 22
Flow rate at 1600 rpm l/mn 52 52
Filtration 35 35
Return µm
Suction µm 15 15
Maximum service pressure bar 125 125
Telescoping circuit bar 250
Lifting circuit bar 190 / 250
Tilt circuit bar 250 / 250
Attachment circuit bar 250 / 190
Steering circuit bar 250
Circuit direction bar 140
647083 EN (21/06/2011)
