2-12
I.C. ENGINE
Type PERKINS 1104D-44T NL38857
Fuel Diesel
Number of cylinders 4 in line
Suction Turbocharged
Injection system Direct
Ignition sequence 1,3,4,2
Capacity cm3 4400
Bore and stroke mm 105 x 127
Compression ratio 18,2:1
Nominal rating loaded rpm 2200
Rating slow unladen rpm 930
Max. rating unladen rpm 2380
Power ISO/TR 14396 cv- kW 95 - 70
Power SAE J 1995 cv- kW 95 - 70
Maximum torque ISO/TR 14396 Nm 392 to 1400 rpm
Air cleaner µm 3
Type of cooling By water
Fan Puller
TRANSMISSION
Gear box TURNER
Type Mechanical
Forward/reverse selector Electro-hydraulic
Torque converter SACHS
Number of forward speeds 4
Number of reverse speeds 4
Angle gear box TURNER
Front axle DANA
Differential Limited slip
Rear axle DANA
Differential Without locking
Drive wheels 4RM Permanent
Switch for 2/4 drive wheels No
Front tyres MICHELIN
Size 400-80 - 24 156A8 IND TL PCL
Pressure bar 3
Rear tyres MICHELIN
Size 400-80 - 24 156A8 IND TL PCL
Pressure bar 3
ELECTRIC CIRCUIT
Battery
Standard 12 V - 110 Ah - 750 A EN
Option 12 V - 145 Ah - 1000 A EN
Alternator 12 V - 85 A
Type Denso Ai115
Starter 12 V - 3,2 kW
Type AZE
BRAKE CIRCUIT
Service brake Non-servo hydraulic brake
Type of brake Multidisk brake immersed in oil
Type of control Foot-operated for the front and rear axles
Parking brake Mechanical
Type of brake Disk on gear-box output
Type of control Manual
CHARACTERISTICS
MT 732 Série E-E3
SOUND AND VIBRATION
Level of sound pressure in the driver’s cab LpA
(according to standard NF EN 12053)
dB 78
Level of sound power ensured in the LwA environment
(according to directive 2000/14/EC modified by directive 2005/88/EC)
dB
104 (measured)
105 (ensured)
Average weighted acceleration on driver’s body
(according to standard NF EN 13059)
m/s2
The average weighted acceleration transmitted to the driver’s hand/arm system
(according to standard ISO 5349-2)
m/s2 < 2,5
