80 Part Number 000015432 4/18
DISPENSE SWITCH
FUNCTION
Supplies power to the product selector switch when
activation lever is depressed.
CHECK
1. Inspect the selector switch for correct wiring.
2. Isolate the switch by disconnecting all wires from the
switch.
3. Check across the switch terminals with an ohm meter.
Activation Lever Position Resistance Reading
Depressed Closed
Released Open
Replace the selector switch if ohm readings do not match.
