Manitowoc CVDF1400 Technician's Handbook

180 Part Number: 000015431 Rev01 5/19
IF0600C/CVDF0600
Remote Air-Cooled Condensing Unit Model
Characteristics vary depending on operating conditions.
All data on this page is preliminary and subject to change
Cycle Times
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
Water Temperature °F/°C
50/10 70/21 90/32
-20 to 70/
-29 to 21
8.9-10.2 9.5-11.0 10.3-11.9
.75-2.5
80/27 9.3-10.7 10.0-11.5 10.9-12.5
90/32 9.6-11.1 10.4-12.0 11.4-13.0
100/38 10.2-11.8 11.1-12.8 12.2-13.9
110/43 11.0-12.6 12.0-13.8 13.2-15.1
1
Times in minutes - Dice cube
24-Hour Ice Production
Air Temp. Entering
Condenser
°F/°C
Water Temperature °F/°C
50/10 70/21 90/32
-20 to 70/
-29 to 21
640 600 560
80/27 615 575 535
90/32 595 555 515
100/38 565 525 485
110/43 530 490 450
1
Based on average ice slab weight of 4.60 - 5.20 lb.
Operating Pressures
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
psig
Suction
Pressure
psig
Discharge
Pressure
psig
Suction
Pressure
psig
-20 to 50/
-29 to 10
200-250 44-26 180-210 65-85
70/21 235-255 50-28 185-210 65-90
80/27 245-275 50-28 190-210 75-100
90/32 250-290 52-30 195-215 75-105
100/38 270-320 52-31 210-240 80-110
110/43 300-360 60-32 215-260 85-115
