Manitowoc Indigo ID0522A User Manual

Part Number STH025 11/16 111
ENERGIZED PARTS CHART REMOTE MODELS
Remote Air-Cooled Condenser Models
Energized Parts Chart
Ice Making
Sequence of
Operation
Water
Pump
Harvest
Valve(s)
Air
Pump(s)*
Water Inlet
Valve
Water
Dump
Valve
Contactor
Coil Liquid
Line Solenoid
Compressor
Condenser
Fan Motor
Length of
Time
Initial Start-Up
1. Water Purge 2. Refrigeration
System Start-up
A. Equalization
On Off Off Off On Off Off Off 45 Seconds
Off On On Off Off Off Off Off 5 Seconds
B. Compressor
Startup
Off On On Off Off On On On 5 Seconds
Freeze Sequence
3. Prechill
Off Off Off
May Cycle
On/Off
during
pre-chill
Off On On On
Initial Start-Up
is 120 Seconds
30 Seconds
thereafter
