Manitowoc Indigo ID0522A User Manual

254 Part Number STH025 11/16
I1106N
Remote Air-Cooled Condenser Model
Characteristics vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
Water Temperature °F/°C
50/10 70/21 90/32
70/21 7.7-9.2 8.6-10.3 9.5-11.3
0.75-2.0
80/27 8.5-10.1 9.5-11.3 10.4-12.3
90/32 9.5-11.3 10.6-12.6 11.4-13.5
100/38 10.7-12.7 11.6-13.8 12.4-14.7
110/43 12.2-14.5 12.7-15.0 13.6-16.1
1 Times in minutes
24 HOUR ICE PRODUCTION
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
50/10 70/21 90/32
70/21 960 870 800
80/27 880 800 740
90/32 800 725 680
100/38 720 670 630
110/43 640 620 580
1 Based on average ice slab weight of 6.2 - 7.2 lb.
OPERATING PRESSURES
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
50/10 200-220 35-22 100-165 70-85
70/21 220-260 40-24 100-170 70-90
80/27 245-285 45-25 100-170 70-95
90/32 250-300 50-27 100-170 70-95
100/38 285-330 60-32 130-180 75-100
110/43 300-375 60-32 130-190 80-100
1 Suction pressure drops gradually throughout the freeze cycle
