Part Number 000007661 6/13 23
Operation
Ice Making Sequence of Operation
NOTE: Flake ice machines use an auger to remove
ice from the evaporator. Occasional noises (creaks,
groans, squeaks, or pops) are a normal part of the ice
making process.
RF0244/RNS0244/RF0266/RF0385/RFS0385/
RNS0385/RF0388/RF0399
Self-Contained Air-Cooled
When the toggle switch is placed in the “ON” position
the following controls must be in the closed position
before the ice machine will start:
A. Bin Thermostat
B. Low Evaporator Temperature Thermostat
C. Low Water Level Switch
Placing the toggle switch in the ON position starts the
gear motor and refrigeration system. The float valve
controls the water inlet valve and water level. The
freeze cycle ends when ice contacts the bin
thermostat. The ice machine will restart when ice no
longer contacts the bin thermostat.
