Manitowoc S300 User Manual

212 Part Number 80-1479-3 7/10
S500N
All Remote Air-cooled Condenser Models Before Serial
Number 110684316
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
-20/-29 to
70/21
9.9-11.7 11.1-13.1 12.6-14.8
1-2.5
80/27 9.9-11.7 11.4-13.4 12.6-14.8
90/32 10.1-11.9 11.4-13.4 12.6-14.8
100/38 10.9-12.8 12.3-14.4 13.3-15.6
110/43 12.0-14.0 13.3-15.6 14.1-16.5
Air Temp. Entering
Condenser
°F/°C
Water Temperature °F/°C
12
1 Based on average ice slab weight of 4.12 - 4.75 lb
2 Ratings with JC0495 condenser dice or half dice cubes
50/10 70/21 90/32
-20/-29 to 70/21 520 470 420
80/27 520 460 420
90/32 510 460 420
100/38 480 430 400
110/43 440 400 380
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
-20/-29 to
50/10
210-240 42-29 105-160 75-100
70/21 235-250 48-31 105-165 85-100
80/27 245-260 50-32 110-165 85-100
90/32 250-270 52-33 110-170 90-105
100/38 265-315 60-34 125-175 90-110
110/43 295-365 62-35 130-185 95-115
