242 Part Number 80-1479-3 7/10
S1400 SERIES
S1400 Self-contained air-cooled
All Self-Contained Air-cooled with a Manufacture Date
Before 0905 (May 2009)
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 8.4-9.4 9.4-10.5 10.0-11.2
1 - 2.5
80/27 8.9-9.9 9.9-11.1 10.8-12.0
90/32 10.2-11.2 10.9-12.2 11.8-13.2
100/38 11.6-12.9 12.8-14.2 13.8-15.4
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 10 - 11 lb.
50/10 70/21 90/32
70/21 1450 1320 1250
80/27 1390 1260 1170
90/32 1250 1160 1080
100/38 1100 1010 940
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 220-280 40-28 150-180 70-90
70/21 220-280 42-28 160-180 70-90
80/27 225-290 44-30 160-180 70-90
90/32 260-310 46-30 180-200 80-100
100/38 290-360 48-31 200-220 90-115
110/43 320-400 50-32 220-250 100-140
