62 Part Number 80-1479-3 7/10
6. Harvest
The air compressor (when used) remains energized
and the harvest valve(s) remains open. The refrigerant
gas warms the evaporator causing the cubes to slide,
as a sheet, off the evaporator and into the storage bin.
Energized Control Board Lights-
Single Evaporators = Left Bin (green), Harvest (red)
Quad Evaporators = All Curtain Switches (green),
Liquid Solenoid (red), Harvest (red), All Harvest Valves
(red)
Single evaporator models - The sliding sheet of
cubes opens the water curtain and bin switch.
The momentary opening and re-closing of the bin
switch terminates the harvest sequence and return to
the freeze sequence (Step 3 - 4.)
Quad evaporator models - The sliding sheet of
cubes opens the ice damper and bin switch. The
momentary opening and re-closing of the bin switch
de-energized the harvest valve for the evaporator.
When all of the bin switches have opened and closed
the ice machine will terminate the harvest sequence
and return to the freeze sequence (Step 3 - 4.)
Energized Control Board Lights (once ice drops)-
Single Evaporators = Left Bin (green flashes once)
Quad Evaporators = All Curtain Switches (green
flashes once), Liquid Solenoid (red)
