S300 SERIES
S300A
All Self-Contained Air-cooled Models Before Serial
Number 110704351
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 9.3-11.0 10.4-12.2 11.5-13.5
1-2.5
80/27 10.0-11.8 11.3-13.2 12.6-14.7
90/32 10.8-12.7 12.3-14.4 13.5-15.7
100/38 12.3-14.4 13.5-15.7 14.8-17.3
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 2.44 - 2.81 lb.
50/10 70/21 90/32
70/21 325 295 270
80/27 305 275 250
90/32 285 255 235
100/38 255 235 215
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10
195-255 50-23 135-160 75-110
70/21 195-260 55-24 135-165 80-110
80/27 220-290 60-25 150-170 90-120
90/32 250-330 70-27 170-195 115-135
100/38 285-370 74-28 200-220 130-155
110/43 330-415 78-30 230-250 150-175
