S1600 SERIES
S1600A
All Self-Contained Air-cooled
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 9.6-10.5 10.7-11.7 11.1-12.2
1 - 2.5
80/27 10.0-11.0 11.3-12.4 12.1-13.2
90/32 11.1-12.2 12.2-13.3 12.2-13.3
100/38 12.5-13.7 13.7-15.0 15.1-16.5
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 13 - 14.125 lb.
50/10 70/21 90/32
70/21 1690 1540 1480
80/27 1630 1460 1380
90/32 1490 1370 1370
100/38 1340 1230 1130
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 220-280 46-27 150-165 70-90
70/21 220-280 50-28 150-165 70-90
80/27 240-300 55-32 155-175 75-95
90/32 270-330 58-34 165-185 80-100
100/38 310-375 65-36 185-200 90-105
110/43 330-415 70-38 200-245 95-115
