HARDWARE CONTENTS (shown actual size)
0[
Screw
Qty. 28
0[
Screw
Qty. 2
NOTE:
(FF) Hardware
preassembled
in door handle
0[
Screw
Qty. 2
NOTE:
(GG) Hardware
preassembled
in lid handle
0[
Screw
Qty. 4
0[
Screw
Qty. 16
Plain
Washer
Qty. 16
6
AA
DD EE
HH
CC
FF
BB
GG
0[
Screw
Qty. 4
Spring
Washer
Qty. 16
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list on previous page and hardware contents above. If any part is missing or damaged, do
not attempt to assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 50 minutes with 2 people.
Tools Required for Assembly and Leak Testing (not included): Phillips screwdriver, Spray bottle
PREPARATION
THIS UNIT IS HEAVY. TWO PEOPLE REQUIRED FOR SAFE ASSEMBLY.
Two people required for safe assembly. Some parts may contain sharp edges. Wear protective
gloves if necessary. Read and follow all safety statements, warnings, assembly instructions and
use and care instructions before attempting to assemble and use.
