Master Forge RT2417S Use Manual

10
Lowes.com/masterforge
ASSEMBLY INSTRUCTIONS
3. Attach the left panel (T) and right panel (N) to
the bottom panel (P). For both the left and
right panels, there are three screws for the
rear panel (L) and four for the bottom panel.
Insert the four bottom panel screws rst.
Hardware Used
AA
3/16-24 x 1/2 in.
Screw
x 14
4. Attach the front beam (U) to the left panel (T)
and the right panel (N) with 2 screws (AA)
on each side as shown.
Hardware Used
AA
3/16-24 x 1/2 in.
Screw
x 4
3
AA
L
N
P
T
AA
U
4
