REPLACEMENT PARTS LIST
Part Description Part #
1 HEAT TENT 2518SL-2003-N
2 COOKING GRID RT2417S-00-2010
3 WARMING RACK RT2417S-00-2020
4 TEMPERATURE GAUGE 2518-3-8012
5 TEMPERATURE GAUGE BEZEL 3218LTN-00-4001
6 TEMPERATURE GAUGE SLEEVE 3218LT-00-4009
7 HOOD RT2417S-00-4000
8 RUBBER PLUG 3219B-8083
9 HOOD HANDLE RT2417S-00-4300
10 SIDE SHELF (LEFT) RT2417S-00-6000
11 SIDE SHELF BRACKET (LEFT) RT2417S-00-2050
12 HOOD SLEEVE 2818-2T-0001
13 BURNER BOX RT2417S-00-2000
14 SIDE SHELF BRACKET (LEFT) RT2417S-00-2040
15 SIDE SHELF (RIGHT) RT2417S-00-5000
16 IGNITION WIRE RT2417S-00-8001
17 LPG REGULATOR L3218-00-8006
18 CONTROL BOX RT2417S-00-3101
19 KNOB BEZEL RT2417S-00-3321
20 KNOB RT2417S-00-3301
21 MAIN BURNER RT2417S-00-8020
22 IGNITION PIN (MAIN BURNER) RT2417S-00-8007
23 IGNITION PIN (MAIN BURNER) RT2417S-00-8008
24 IGNITION PIN (MAIN BURNER) RT2417S-00-8009
Part Description Part #
25 MANIFOLD RT2417S-00-3200
26 LEFT PANEL RT2417S-00-1700
27 SAFETY TANK RING RT2417S-00-1203
28 TANK RING BRACKET 2518SL-1203
29 REAR PANEL RT2417S-00-1200
30 IGNITER RT2417S-00-8004
31 RIGHT PANEL RT2417S-00-1800
32 BOTTOM PANEL RT2417S-00-1100
33 LOCKING CASTER RT2417S-00-8005
34 CASTER RT2417S-00-8006
35 MATCH HOLDER 3019L-1710
36 DOOR RT2417S-00-1600
37 DOOR HANDLE RT2417S-00-1610
38 BEAM RT2417S-00-1500
39 DRIP TRAY SUPPORT RT2417S-00-1900
40 DRIP TRAY RT2417S-00-1002
S1 SCREW 1/4-20 x 5/8"
S2 SCREW 5/16-18UNC x 3/4"
S3 NUT 5/16-18UNC
S4 SCREW M4 × 8
S5 SCREW 3/16-24UNC x 1/2"
S6 SCREW 5/32-32UNC x 3/8"
S7 R PIN R PIN
