IMPORTANT INFORMATION
AIR-POWERED STAPLER 058-8132-2
12
Air system
• Always use clean, dry, regulated, compressed air at 4.8 to 7 bar (70 to 100 psi).
• Do not exceed the maximum or minimum pressures. Operating the tool at the wrong pressure
(too low or too high) will cause excessive noise or rapid wear.
WARNING!
Potential hazard that could result in serious injury or loss of life.
• Keep hands and other body parts away from the tool’s discharge and working
areas when connecting the air supply. Failure to comply could lead to serious
injury or loss of life.
No. Description No. Description
1 Mastercraft
®
Air-powered Stapler 6 Regulator (0 to 8.5 bar)
2 Quick connector 7 Filter
3 Quick coupler 8 Cut-off valve
4Air hose 9Air compressor
5 Lubricator
2
5
7
1
3
3
6
8
9
4
MC-8132-10
