Matrix G1-GM30 User Manual

20
4.5 SEAT ADJUSTMENT HANDLE REPLACEMENT
1) Use a 24MM Open-Ended Wrench to take off the old adjustment pin set (Figure A).
2) Install a new adjustment pin (Figure B).
Figure A Figure B
4.6 BACK ADJUSTMENT HANDLE REPLACEMENT
1) Use a 24MM Open-Ended Wrench to take off the old adjustment pin set (Figure A).
2) Install a new adjustment pin (Figure B).
Figure A Figure B

Matrix G1-GM30 Specifications

General

Brand	Matrix
Model	G1-GM30
Category	Fitness Equipment
Language	English
