3. MCB CIRCUIT BOARD INSTRUCTIONS (T70/T75) (110V)
10
JP01
Drive motor cable socket
JP02
Power Line in socket
JP3
Console set cable socket
JP4
Incline motor cable socket
JP05
Fan cable socket
