Matrix U30 Service Manual

19
CHAPTER 4: Part Replacement Guide
4.2 HANDLEBAR REPLACEMENT
For U50
1) Remove the console (section 4.1).
2) Remove the four screws from the handlebar (Fig1).
3) Remove four screws on both heart grips (Fig2).
4) Remove four screws which lock the quick keys (Fig3).
5) Reverse the steps one to install a new handlebar (Fig4).
Fig1 Fig2
Fig3 Fig4

Matrix U30 Specifications

General

Resistance Type	Magnetic
Drive System	Belt
Display Type	LCD
Console Display	LCD
Max User Weight	350 lbs
Warranty	5 years frame, 3 years parts, 1 year labor
